AC Power Supply, 100-240V AC in, 12V DC 3A out
Product information "AC Power Supply, 100-240V AC in, 12V DC 3A out"
This is a desktop-type AC power suppy for 12V DC / 3A output.
It is a suitable as a accessory (or replacement part) for the following products
NOTE: There is no primary AC cable included, please provide one yourself or check the accessories listed below under C7 cables
| AC Input | 100-240V AC, +/-10%, 47-63 Hz |
| Input Currrent | 100V AC: 0.45A |
| Inrush current | limited to 60A peak |
| Efficiency | Meets EISA2007, CEC Efficiency Level V, EU (EC) No 278/2009 Phase I |
| Output Voltage | 12V |
| Output Current | 3A (max) |
| Output Ripple | 1 .. 6% |
| MTBF | 50,000 hours (calculated) |
| Operating Temperature | 0 to 40 centigrade, no derating |
| Output Connector | 2.5mm barrel type, center contact + |
| Output Cable | 1.5m +/- 5cm |
| Input Connector | ICE320 - C8 |
Login
C7 cables
AC power cable C7 Plug (US Version)
€5.95*
This is an AC power cable with an IE320 - C7 plug (for C8 sockets) on
the device side, and an US plug for the wall-outlet side. The length
is 1.3m.It is compatible with the sysmoBTS 1002 power supply and can be used as a spare part.
AC power cable C7 Plug (EU Version)
€5.95*
This is an AC power cable with an IE320 - C7 plug (for C8 sockets) on
the device side, and an EU/European plug for the wall-outlet side. The
length is 1.3m.It is compatible with the sysmoBTS 1002 power supply and can be used as a spare part.
